Cast Iron Electric Sump Oil Recovery Diaphragm Pump

Cast Iron Electric Sump Oil Recovery Diaphragm PumpCapacity: 0.75~20 m3/hHead: less than 30mSize: 10~100 mmMedium temperature: -15~90 degreeMaterial: Stainless Steel, Cast Iron, AluminiumDescriptions:DBY electric driven diaphragm pump  has good suction ability, no leakage, no clogging,  It doesn\'t need the l

Featured Products

Cast Iron Electric Sump Oil Recovery Diaphragm Pump


Capacity: 0.75~20 m3/h
Head: less than 30m
Size: 10~100 mm
Medium temperature: -15~90 degree
Material: Stainless Steel, Cast Iron, Aluminium

Descriptions:

DBY electric driven diaphragm pump  has good suction ability, no leakage, no clogging,
It doesn't need the lead water, and has self-sucking function. Good pass capability
that the big grain impurity and slurry can be passed easily.

Features:

DBY electric driven diaphragm pump

1. capacity : 0.5-20m³/h
2.head: 30m
3.temperature: below110 celsius degree
4.suction height:6m
5.material:cast iron, alumium, stainless steel, engineering plastic,perfluoro rubber

Advantages:

DBY electric driven diaphragm pump
1.non irrigate and non lead water
2.good passing performance
3.simple  structure

Apply to :

1. Pump for peanut butter, pickles, mashed potato, sausage, chocolate, hops, syrup;
2. Pump for paint, pigment, gluewater, adhesive;
3. Pump for all kinds of tile,porcelain, brick and ceramics glaze slip;
4. Pump for all kinds of abrasive, corrosive, oil dirties;
5. Pump for all kinds of toxic, flammable and easy-to-play liquid;
6. Pump for sewage, cement granting and mortar;
7. Pump for all kinds of strong acid, strong base and strong corrosive liquid;
8. As the first stage device for all kinds of quipment for separating solid and liquid

 Name
 Type

 Inlet/Outlet Size
(mm)

 Capacity
(m 3 /h)

 Head
(m)

 Suction
(m)

Max allowable by diameter
φ(mm)

 Motor
(KW)

  DBY Electric
Diaphragm Pump


DBY-10

10

0.5

30

3

1

0.55

DBY-15

15

0.75

30

3

1

0.55

DBY-25

25

3.5

30

4

2.5

1.5

DBY-40

40

4.5

30

4

4.5

2.2

DBY-50

50

6.5

30

4.5

8

4

DBY-65

65

8

30

4.5

8

4

DBY-80

80

16

30

5

10

5.5

DBY-100

100

20

30

5

10

7.5


RFQ

1. How to get our quotation in time, pls answer following questions:

    1)What liquid do you transfer? Oil, Water, Food or Corrosive Chemical liquid, with solid particle or not, and so on~

   2) What's the flow or capcity (m3/h, L/m)?

   3) What's the discharge head (m, feet, Mpa, bar )

 If you do not have any request, we will do as our normal standard.

4) Contact us to get the quotation

2.OEM: Ok

3. MOQ: 1set

4. Package: Standar export Plywood Case or Styrofoam with Carton

5. Shipping ways: By sea, By air, By express

6. Lead time: 3-15days

7. Term of  payment:  100% T/T, Aliexpress,  L/C, Westunion

8. Warranty Period: One year, except spare parts

9. Why choose KAICHENG:  Decades experiences manufacturer

                                                Good quality with competitive pirce

                                                 ISO, CE certificate

                                      Professional after-sales service
